EPS Sandwich Wall Panel Equipment , CE Fiber Cement Board Production Line
EPS Sandwich Wall Board Forming Machine / Fiber Cement Board Production Line
1. Specification of Wall Board:
Length: unlimited.
Width: 60cm ---- 120cm (Adjustable)
Thickness: 1cm----15cm (Adjustable)
2. Machine Model:
According to different production capacity from 800 square meters to 3000 square
meters per eight hours wall board-making machine has different models for large-scale, middle-scale and small-scale.
All machine can produce board with same best-quality and specification board, only
has different production capacity.
For whole production line, we have common one, semi-automatic one and
full-automatic one, you can choose any kind of production line according to your own
condition.
3. Application of Wall Board:
The wall board produced by our machine will replace solid brick as indoor partition,
wall of steel structure and frame structure as well as wall of removable houses. Its
products can be used for outside wall heat-preserving in northeast area of China.
4. Board performance:
|
1
|
Air-dry density
|
≤ (Standard index)50kg/m2
|
(Test Value) 30.0kg/ m2
|
|
2
|
Drying shrinkage
rate of the board
|
≤0.08%
|
0.015%
|
|
3
|
Anti-breaking load
|
≥1400N
|
5640N
|
|
4
|
Anti-impact
|
No breakage phenomenon
such as cracking after
three impacts
|
No breakage
phenomenon such as
cracking after three
impacts
|
|
5
|
Thermal resistance
of main section (T=90mm)
|
≥1.35(m2.k)/w
|
≥1.36(m2.k)/w
|
|
6
|
Thermal bridges area ratio
|
≤8%
|
2.22%
|
|
7
|
Sound reduction Index
|
|
36dB
|
|
8
|
Radioactivity
|
|
None
|
5. After-sale
After purchased the equipment, we will teach relevant technology for free, and will
go to your factory for installation and testing until you can produce the qualified
product by yourself. Our company will train 2-3 technical personnel for free until he
can get the skill. We will take responsibility for provide technical consultation and
following-up service for a long time, the equipment warranty period is one year
• With reasonable structure, the machine is easy to operate with completed functions. The plate is formed through such processes as feeding, profiling, dispensing, heating, trimming, gouging and cutting.
• This machine adopts precise low-speed metering pump, frequency control (or stepless speed variation) with computer control and dose is accurate.
• This machine may produce flat plate and corrugated sheet of many specifications and models, including the sandwich panel with thickness of 40-300mm and width of 950-1200mm, and corrugated high-intensive composite board with thickness of 40-300mm and width of 950-980mm.
• This machine applies to color steel plate, aluminum plate, stainless steel plate and so on.
| mgo wall board machine |
2000SQM |
| |
|
